Product Summary

The CB2012T220M is a wound chip inductor. It is suitable for DVC, MD, PDA and other portable digital equipment.

Parametrics

CB2012T220M absolute maximum ratings: (1)operating TEMP: -25 to 85℃; (2)Frequency - Self Resonant: 16MHz; (3)DC Resistance (DCR): 2.21 Ohm Max; (4)Inductance :22μH; (5)Tolerance: ±20%; (6)Current: 280mA.

Features

CB2012T220M features: (1)Small size wound chip inductor with high current; (2)Demension without directional influence on mounterbility and characteristics; (3)For DC-DC converter circuit.

Diagrams

CB2012T220M external dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CB2012T220M
CB2012T220M
Taiyo Yuden
Power Inductors INDCTR HI CUR WND 0805 22uH 20%
Data Sheet
0-1: $0.11
1-10: $0.11
10-50: $0.10
50-100: $0.09
