Product Summary
The MBR10100G is a switch mode power rectifier. It uses the Schottky Barrier principle with a platinum barrier metal.
Parametrics
MBR10100G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 100V; (2)Working Peak Reverse Voltage, VRWM: 100V; (3)DC Blocking Voltage, VR: 100V; (4)Average Rectified Forward Current (Rated VR) TC = 133℃, IF(AV): 10 A; (5)Peak Repetitive Forward Current (Rated VR, Square Wave, 20 kHz) TC = 133℃, IFRM: 20 A; (6)Nonrepetitive Peak Surge Current, IFSM: 150 A; (7)Peak Repetitive Reverse Surge Current, IRRM: 0.5 A; (8)Operating Junction Temperature, TJ: -65 to +175℃; (9)Storage Temperature, Tstg: -65 to +175℃; (10)Voltage Rate of Change (Rated VR), dv/dt: 10,000 V/μs.
Features
MBR10100G features: (1)Guard-Ring for Stress Protection; (2)Low Forward Voltage; (3)175℃ Operating Junction Temperature; (4)Epoxy Meets UL 94 V-0 @ 0.125 in; (5)Low Power Loss/High Efficiency; (6)High Surge Capacity; (7)Low Stored Charge Majority Carrier Conduction; (8)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MBR10100G |
ON Semiconductor |
Schottky (Diodes & Rectifiers) 10A 100V |
Data Sheet |
|
|
||||||||||||
