Product Summary

The 10BQ040TRPBF is a surface-mount Schottky rectifier. It has been designed for applications requiring low forward drop and very small foot prints on PC boards. Typical applications of the 10BQ040TRPBF are in disk drives, switching power supplies, converters, free-wheeling diodes, battery charging, and reverse battery protection.

Parametrics

10BQ040TRPBF absolute maximum ratings: (1)IF(AV), Rectangular waveform: 1.0 A; (2)VRRM: 40 V; (3)IFSM @ tp = 5 μs sine: 430 A; (4)VF @ 1.0 Apk, TJ=125℃: 0.49 V; (5)TJ range: - 55 to 150℃.

Features

10BQ040TRPBF features: (1)Small foot print, surface mountable; (2)Low forward voltage drop; (3)High frequency operation; (4)Guard ring for enhanced ruggedness and long term; (5)reliability; (6)Lead-Free (PbF suffix).

Diagrams

10BQ040TRPBF Outline Table

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
10BQ040TRPBF
10BQ040TRPBF


DIODE SCHOTTKY 40V 1A SMB

Data Sheet

0-1: $0.31
1-10: $0.25
10-25: $0.22
25-100: $0.19
100-250: $0.16
250-500: $0.14
500-1000: $0.11
