XC6219A332MR

LDO Voltage Regulator, SOT-25, 7.0 V, 500 mA, 100 mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.04~0.07 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.04~0.07

PartNumber:: XC6219A332MR

Brand:: Torex Semiconductor - TOREX | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ray Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-02-02

From Other Seller

Part Number:XC6219A332MR
US $0.04 - 0.07
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
PIC16F917-I/P(PIC16F917-IP)

US $1.60 - 2.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The XC6219A332MR is a highly accurate, low noise, CMOS . Offering low output noise, high ipple rejection ratio, low dropout and very fast turn-on times, the device is ideal for today’s cutting edge mobile phone. The applications of the XC6219A332MR include Mobile phones, Cordless phones, radio communication equipment, Portable games, Cameras, Video cameras, Reference voltage sources and Battery powered equipment .

Parametrics

XC6219A332MR absolute maximum ratings: (1)Input Voltage, VIN: 7.0 V; (2)Output Current, IOUT: 500 mA; (3)Output Voltage, VOUT: VSS - 0.3 ~ VIN + 0.3 V; (4)CE Pin Voltage, VCE: VSS - 0.3 ~ VIN + 0.3 V; (5)Power Dissipation, Pd: 100 mW; (6)Operating Temperature Range, Topr: - 40 ~ + 85℃; (7)Storage Temperature Range, Tstg: - 55 ~ + 125℃.

Features

XC6219A332MR features: (1)Maximum Output Current: 150mA (VOUT<1.75V, A~D type); 240mA (VOUT>1.8V, A~D type); 300mA (VOUT>1.3V, E~H type); (2) Dropout Voltage: 200mV @ 100mA; (3)Operating Voltage Range: 2.0V ~ 6.0V; (4)Output Voltage Range: 0.9V ~ 5.0V (0.05V steps); (5)Highly Accuracy: +2% (VOUT>1.5V); +30mV (VOUT≦1.5V) ; +1% (VOUT≧3.0V) ; (6)Low Power Consumption : 25μA (TYP.); (7)Standby Current: Less than 0.1μA (TYP.); (8)High Ripple Rejection: 65dB @10kHz ; (9)Operating Temperature Range: -40℃ ~ 85℃; (10)Low ESR Capacitor: Ceramic capacitor compatible; (11)Ultra Small Packages: SOT-25, SOT-89-5, USP-6B; (12)Environmentally Friendly: EU RoHS Compliant, Pb Free.
