Product Summary
The SPLPL90-3 is a Pulsed Laser Diode in Plastic Package 25 W Peak Power. Depending on the mode of operation, the device emits highly concentrated non visible infrared light which can be hazardous to the human eye. The applications of the SPLPL90-3 include Range finding, Security, surveillance, Illumination, ignition and Test and measurement systems.
Parametrics
SPLPL90-3 absolute maximum ratings: (1)Peak output power, Ppeak: 30 W; (2)Forward current, IF: 40 A; (3)Pulse width (FWHM), tp: 100 ns; (4)Duty cycle, d.c: 0.1 %; (5)Reverse voltage, VR: 3 V; (6)Operating temperature, Top: - 40 to +85℃; (7)Storage temperature, Tstg: - 40 to +100℃; (8)Soldering temperature, Ts: +260℃.
Features
SPLPL90-3 features: (1)Low cost plastic package; (2)Reliable strained InGaAs/GaAs material; (3)High power large-optical-cavity (LOC) structure for a narrow far-field; (4)Lateral laser aperture 200 μm.
Diagrams
 |
