IRFL4105TR

HEXFET, SOT223, 55V, 3.7A, N-Channel, 1W, 660pF, Surface Mount, MOSFET

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.15~0.19 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.15~0.19

PartNumber:: IRFL4105TR

Brand:: International Rectifier - IR | Pack: SOT | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Ray Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-01-05

From Other Seller

Part Number:IRFL4105TR
US $0.15 - 0.19
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
TOP259EN

US $1.10 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IRFL4105TR is a Fifth Generation HEXFET from International Rectifier utilizes advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit, combined with the fast switching speed and ruggedized device design that the IRFL4105TR is well known for, provides the designer with an extremely efficient and reliable device for use in a wide variety of applications. The SOT-223 package is designed for surface-mount using vapor phase, infra red, or wave soldering techniques. IRFL4105TR unique package design allows for easy automatic pickand-place as with other SOT or SOIC packages but has the added advantage of improved thermal performance due to an enlarged tab for heatsinking. Power dissipation of 1.0W is possible in a typical surface mount application.

Parametrics

IRFL4105TR absolute maximum ratings: (1)ID @ TA = 25℃ Continuous Drain Current, VGS @ 10V: 5.2A; (2)ID @ TA = 25℃ Continuous Drain Current, VGS @ 10V: 3.7A; (3)ID @ TA = 70℃ Continuous Drain Current, VGS @ 10V: 3.0A; (4)IDM Pulsed Drain Current: 30A; (5)PD @TA = 25℃ Power Dissipation (PCB Mount): 2.1 W; (6)PD @TA = 25℃ Power Dissipation (PCB Mount): 1.0 W; (7)Linear Derating Factor (PCB Mount): 8.3 mW/℃; (8)VGS Gate-to-Source Voltage: ± 20 V; (9)EAS Single Pulse Avalanche Energy: 110 mJ; (10)IAR Avalanche Current: 3.7 A; (11)EAR Repetitive Avalanche Energy: 0.10 mJ; (12)dv/dt Peak Diode Recovery dv/dt: 5.0 V/ns; (13)TJ, TSTG Junction and Storage Temperature Range: -55 to + 150 ℃.

Features

IRFL4105TR features: (1)Surface Mount; (2)Advanced Process Technology; (3)Ultra Low On-Resistance; (4)Dynamic dv/dt Rating; (5)Fast Switching; (6)Fully Avalanche Rated; (7)Lead-Free.
